SYSTEMS LAB · MISSION 05
HEAT SIMULATION

YEAR 7 · TERM 3 · WEEK 5

Heatwave

How does heat move?

HEATWAVE · THERMAL RESPONSE CENTRE: A fictional emergency water supply is warming too quickly as outside temperatures rise. Your mission is to trace how thermal energy is crossing the system boundary, compare materials fairly and recommend a design that slows unwanted temperature change without pretending any material can stop heat transfer completely.
MISSION DECKSYSTEMS LAB / WEEK 05SELECT A MODULE
ACTIVE OBJECTIVEHEATWAVE · THERMAL RESPONSE CENTRE: A fictional emergency water supply is warming too quickly as outside temperatures rise. Your mission is to trace how thermal energy is crossing the system boundary, compare materials fairly and recommend a design that slows unwanted temperature change without pretending any material can stop heat transfer completely.
WORLDSYSTEMS LAB
SEQUENCE01 / 08
REWARDGAME BREAK
Jump to a lesson part

READY?

Watch. Check the clues. Have a go.

Everything you need is on this page.

Start mission →
Need help getting started?
YOU NEED
  • Required: a device with this page open.
  • Optional: headphones for video or read-aloud.
  • Optional: pen + paper for rough working if that helps you think.
HOW TO DO IT
  1. Read or listen to the Briefing + Learn.
  2. Do the interactive mission.
  3. Use facts from the reading and maths parts.
  4. Make your choice and save your project step.
  5. Play the weekly game. Finish Check-in.
WORK YOUR WAY

Short bursts are fine. Use Learning Tools for easier reading, read-aloud, less on screen, stronger contrast, no-rush and quieter-screen options.

If you get stuck, look at the example and try again.

SCIENCE SAFETY: The science investigations in this Senior mission are designed as virtual/screen-based activities unless the page clearly says otherwise. Do not improvise mains electricity, heating or chemical experiments at home.

PROJECT NOTE: Your project can stay digital. Physical making is optional unless you choose that format.

MISSION BRIEFING

HEATWAVE · THERMAL RESPONSE CENTRE: A fictional emergency water supply is warming too quickly as outside temperatures rise. Your mission is to trace how thermal energy is crossing the system boundary, compare materials fairly and recommend a design that slows unwanted temperature change without pretending any material can stop heat transfer completely.

✓Distinguish conduction, convection and radiation using observable examples.
✓Explain that thermal energy transfers from warmer regions toward cooler regions and that different materials affect the rate of transfer.
✓Distinguish conductors from insulators without describing insulation as “making cold”.
✓Design a fair virtual comparison by changing one main variable while holding starting conditions and other relevant factors constant.
✓Use a temperature series to compare designs and make an evidence-based recommendation with a stated limitation.

MISSION MEDIA · Cognito

Conduction, Convection & Radiation

Identify conduction, convection and radiation before running the insulation tests.

YOUTUBE ↗

Tap Watch video to load the YouTube player. You can turn captions on in the player. If it will not play, use the YouTube link.

LEARN

TEMPERATURE DIFFERENCE → TRANSFER → RATE → DESIGN

THERMAL ENERGY moves when there is a temperature difference. CONDUCTION transfers energy through direct particle interactions, especially through solids. CONVECTION transfers energy through the movement of fluids such as air or water. RADIATION transfers energy by electromagnetic waves and does not require direct contact. Conductors allow thermal energy to transfer relatively quickly; insulators slow that transfer. In an insulation investigation, use TEMPERATURE DIFFERENCE → TRANSFER PATHWAY → RATE → EVIDENCE → DESIGN. A good insulator reduces the rate of transfer; it does not create cold or stop transfer forever.

LEARNING BUILD

Learn it. See it. Try it.

Look at the example, then try the task below.

Step 1: Choose a starting clue
WHAT YOU ALREADY KNOW

Reasoning lens:SYSTEM → PARTS → CHANGE / PRESSURE → EFFECT → EVIDENCE → LIMIT

What do you already know?

English / communication:Experimental explanation, method writing and evidence-based recommendation.

Maths / data:Temperature series, differences, averages and graph interpretation.

Topic knowledge:Thermal energy transfer by conduction, convection and radiation; conductors, insulators and fair testing.

This week’s first target:Distinguish conduction, convection and radiation using observable examples.

Which clue is a good place to start?

Choose a source that can directly support part of the investigation. More than one source may be useful, but start with evidence that does not outrun its support.

Need more help? See the teaching
TEACH 1 · CORE MODEL

THERMAL ENERGY moves when there is a temperature difference. CONDUCTION transfers energy through direct particle interactions, especially through solids. CONVECTION transfers energy through the movement of fluids such as air or water. RADIATION transfers energy by electromagnetic waves and does not require direct contact. Conductors allow thermal energy to transfer relatively quickly; insulators slow that transfer. In an insulation investigation, use TEMPERATURE DIFFERENCE → TRANSFER PATHWAY → RATE → EVIDENCE → DESIGN. A good insulator reduces the rate of transfer; it does not create cold or stop transfer forever.

TEACH 2 · WHAT TO NOTICE

Distinguish conduction, convection and radiation using observable examples.Explain that thermal energy transfers from warmer regions toward cooler regions and that different materials affect the rate of transfer.

TEACH 3 · CONNECT + TRANSFER

Distinguish conductors from insulators without describing insulation as “making cold”. Design a fair virtual comparison by changing one main variable while holding starting conditions and other relevant factors constant. Use a temperature series to compare designs and make an evidence-based recommendation with a stated limitation.

WORKED EXAMPLE · EVIDENCE

BASELINE · virtual model

A fictional 6°C water supply in 32°C surrounding air reaches 15.0°C after 20 modelled minutes in a bare-metal container with the lid closed in shade.

Reasoning: Start with exactly what the source establishes. Connect it to the relevant concept, then stop before the claim becomes broader than the evidence. Now compare it with OVERCLAIM: A fictional claim says “insulation prevents heat from entering at all”. The model supports a slower rate of transfer, not zero transfer.

Why caution still matters:This item is weak evidence for a broad conclusion: its claim or implication reaches beyond what the available support can establish.

WORKED EXAMPLE · MATHS / DATA ROUTE

The bare-metal model rises from 6.0°C to 15.0°C, while the foam model rises from 6.0°C to 8.6°C. How much smaller is the foam model’s temperature rise?

This week’s maths/data focus:Temperature series, differences, averages and graph interpretation.

Name the variable or relationship, keep the units visible, calculate or compare, then interpret the result as evidence about the system. A result can support an explanation without proving every possible cause.

Worked solution:Bare metal rises 15.0 − 6.0 = 9.0°C. Foam rises 8.6 − 6.0 = 2.6°C. The foam rise is 9.0 − 2.6 = 6.4°C smaller.Answer check:6.4°C. Now return the result to the question and state what it means in context.

WE DO · GUIDED PRACTICE

Which source needs the most caution before it is used to support a broad conclusion?

Choose any source whose claim outruns its support.

YOU TRY · INDEPENDENT PRACTICE

For Heatwave, explain one core idea in your own words. Use one named source or observation from this page, then add one sentence saying what that evidence does NOT prove.

Write at least 18 words. Name the evidence or data you are using and keep the claim inside what it can support.

MISCONCEPTION CHECK

OVERCLAIM:A fictional claim says “insulation prevents heat from entering at all”. The model supports a slower rate of transfer, not zero transfer.

This item is weak evidence for a broad conclusion: its claim or implication reaches beyond what the available support can establish.

HELP

Try: “The system part/variable ___ changes ___. The evidence is ___. This suggests ___. One limit is ___.”

STRETCH · OPTIONAL

Add a second source, data point or test. Explain whether it strengthens, weakens or qualifies your first conclusion.

THERMAL RESPONSE CENTRE · HEATWAVE

HEATWAVE

Slow the energy transfer. Protect the supply.

Identify conduction, convection and radiation, then run controlled virtual insulation tests and decide which design slows unwanted temperature change.

HEAT TRANSFER ID · 3 MODES
CASE 1

A metal spoon becomes warm from the end sitting in hot soup.

CASE 2

Warm fluid rises while cooler fluid sinks, creating a circulating current.

CASE 3

You feel warmth from the Sun without touching it.

VIRTUAL EMERGENCY SUPPLY TEST

Keep a cold water supply cool during a heatwave.

This is a simplified virtual model. The starting water temperature is 6°C and the surrounding air is 32°C. Your job is to compare designs fairly, not to perform a hot/cold experiment at home.

WALL MATERIAL
LID
LOCATION
0 MIN6.0°C
5 MIN—
10 MIN—
15 MIN—
20 MIN—
BASELINENOT LOGGED

Bare metal · lid closed · shade.

CONTROLLED COMPARISONNOT LOGGED

Cardboard · lid closed · shade.

CONTROLLED COMPARISONNOT LOGGED

Foam · lid closed · shade.

CONDUCTOR OR INSULATOR?

Why can an insulating layer help the supply stay cool for longer?

FAIR TEST AUDIT

To compare insulating materials, which plan gives the clearest evidence?

SYSTEMS THINKING

Which conclusion best fits an insulation test?

Identify all three heat-transfer modes, complete the three controlled insulation runs, then pass the insulation, fair-test and system-limit checks.

OPEN THE WEEK 5 EVIDENCE FILES
SOURCE 1

BASELINE · virtual model

A fictional 6°C water supply in 32°C surrounding air reaches 15.0°C after 20 modelled minutes in a bare-metal container with the lid closed in shade.
SOURCE 2

CARDBOARD TEST

With the same start temperature, closed lid and shaded location, the cardboard-layer model reaches about 11.0°C after 20 minutes.
SOURCE 3

FOAM TEST

With the same start temperature, closed lid and shaded location, the foam-insulated model reaches about 8.6°C after 20 minutes.
SOURCE 4

DIRECT SUN CONTEXT

The teaching model predicts a faster temperature rise in direct sun. Real heating rates depend on many factors including material thickness, colour, airflow, geometry and weather.
SOURCE 5

OVERCLAIM

A fictional claim says “insulation prevents heat from entering at all”. The model supports a slower rate of transfer, not zero transfer.

INVESTIGATE + ENGLISH · EVIDENCE CASE

Insulation changes the rate, not the direction of energy transfer

During the fictional heatwave, the water supply begins cooler than the surrounding air. Thermal energy therefore tends to transfer from the warmer surroundings toward the cooler contents. Some transfer can occur through the container walls by conduction, through moving air by convection and through radiation from warmer surroundings or sunlight. Insulation is useful because it can reduce the rate of this transfer. To compare materials fairly, the starting temperature, lid position, location and test duration should remain consistent while the wall material changes. The virtual results can then be compared, but they are still a model rather than a guarantee of how every real container will perform.

MAKE THE CALL

Your decision

Choose one feature to improve first: wall insulation, lid design or shade. Use the test results to explain which way heat travels and how your change could slow it down. Name one extra test before using the design in a real emergency.

HOW TO EXPLAIN YOUR CHOICE
  1. Say what you chose.
  2. Use at least two clues that help explain your choice.
  3. Say what the clues cannot tell you, or what you are still unsure about.
  4. Finish by saying what you can conclude from those clues.
You can start with: I chose… The clues show… I am still unsure about… So I think…

YOUR WRITING TASK: Write 180–240 words. Use these steps to plan your answer.

  1. Recommend a design for the made-up emergency water supply.
  2. Explain conduction, convection and radiation: three ways heat energy travels.
  3. Compare at least two temperature results after 20 minutes.
  4. For the fair material test, name what you changed and what you measured. Explain one way the virtual model differs from real life.

0/180 words minimum for this writing mission.

CLAIMEVIDENCELIMITATIONCONCLUSION

MATHS + DATA LAB

Check the numbers.

HOW TO SUCCEEDRead the question. Make a rough guess. Work out your answer, then use the feedback to check it.For data questions, say what the number tells you and what it cannot tell you.

The bare-metal model rises from 6.0°C to 15.0°C, while the foam model rises from 6.0°C to 8.6°C. How much smaller is the foam model’s temperature rise?

WORKED METHOD · READ BEFORE YOU TRYBare metal rises 15.0 − 6.0 = 9.0°C. Foam rises 8.6 − 6.0 = 2.6°C. The foam rise is 9.0 − 2.6 = 6.4°C smaller.

MISSION 05 · MATHS + DATA LAB

DATA TRAINING

MEASUREMENT + GEOMETRY · YEAR 7 CORE
6 PROBLEMS
QUICK METHODMEASUREMENT + GEOMETRY

Write the correct formula or conversion before substituting values.

First, let’s learn how to do it

Read these worked steps before choosing an answer. Use the clue under any question whenever you need it. There is no penalty for trying again.

  1. Area is inside a shape: for a rectangle use length × width.
  2. Perimeter is around a shape: add every side. An 8 m by 5 m rectangle has perimeter 8 + 5 + 8 + 5 = 26 m.
  3. Angles in a triangle total 180°. If two angles are 50° and 60°, the third is 180 − 50 − 60 = 70°.

See it another way

Second area example: a triangle has base 10 cm and perpendicular height 6 cm. It is half of a 10 × 6 rectangle, so area = 10 × 6 ÷ 2 = 30 cm².

Volume counts cubes inside a solid. A box 4 cm × 3 cm × 2 cm holds 4 × 3 = 12 cubes in each layer and 2 layers: 24 cm³. A 3 cm cube has 3 × 3 × 3 = 27 cm³.

Unit check: 1 m = 100 cm, so 2.5 m = 250 cm. Area uses square units and volume uses cubic units. A straight angle is 180°; a full turn is 360°.

Try with help

A rectangle is 6 m long and 4 m wide. What is its perimeter in metres?

Show the first step

Perimeter is the distance around all four sides, not the space inside.

This practice helps you prepare. It does not complete the questions below.

Show the full method

6 + 4 + 6 + 4 = 20 m. Multiplying 6 × 4 gives area, 24 m², which answers a different question.

GUIDED · Q01–Q03Use the quick method, then check the explanation.
Q01

Rectangle 8 m × 5 m. Area?

Need a clue? Show me a step

Area measures the space inside. For a rectangle, multiply length by width.

Show the method to use
  1. Area is inside a shape: for a rectangle use length × width.
  2. Perimeter is around a shape: add every side. An 8 m by 5 m rectangle has perimeter 8 + 5 + 8 + 5 = 26 m.
  3. Angles in a triangle total 180°. If two angles are 50° and 60°, the third is 180 − 50 − 60 = 70°.
Work through this question

Area = length × width = 8 × 5 = 40 m².

Now close the method and try the question again. Reading the method does not mark it complete.

Q02

Rectangle 8 m × 5 m. Perimeter?

Need a clue? Show me a step

Perimeter measures the distance around. Add all four sides.

Show the method to use
  1. Area is inside a shape: for a rectangle use length × width.
  2. Perimeter is around a shape: add every side. An 8 m by 5 m rectangle has perimeter 8 + 5 + 8 + 5 = 26 m.
  3. Angles in a triangle total 180°. If two angles are 50° and 60°, the third is 180 − 50 − 60 = 70°.
Work through this question

Perimeter = 8 + 5 + 8 + 5 = 26 m.

Now close the method and try the question again. Reading the method does not mark it complete.

Q03

A straight angle measures…

Need a clue? Show me a step

Picture two right angles forming one straight line.

Show the method to use
  1. Area is inside a shape: for a rectangle use length × width.
  2. Perimeter is around a shape: add every side. An 8 m by 5 m rectangle has perimeter 8 + 5 + 8 + 5 = 26 m.
  3. Angles in a triangle total 180°. If two angles are 50° and 60°, the third is 180 − 50 − 60 = 70°.
Work through this question

A straight line forms a 180° angle.

Now close the method and try the question again. Reading the method does not mark it complete.

INDEPENDENT · Q04

2.5 m equals…

Need a clue? Show me a step

One metre is 100 centimetres. Multiply metres by 100.

Show the method to use
  1. Area is inside a shape: for a rectangle use length × width.
  2. Perimeter is around a shape: add every side. An 8 m by 5 m rectangle has perimeter 8 + 5 + 8 + 5 = 26 m.
  3. Angles in a triangle total 180°. If two angles are 50° and 60°, the third is 180 − 50 − 60 = 70°.
Work through this question

1 m = 100 cm, so 2.5 m = 250 cm.

Now close the method and try the question again. Reading the method does not mark it complete.

INDEPENDENT · Q05

A triangle has angles 50° and 60°. Third angle?

Need a clue? Show me a step

The three inside angles add up to 180°. Subtract the two known angles.

Show the method to use
  1. Area is inside a shape: for a rectangle use length × width.
  2. Perimeter is around a shape: add every side. An 8 m by 5 m rectangle has perimeter 8 + 5 + 8 + 5 = 26 m.
  3. Angles in a triangle total 180°. If two angles are 50° and 60°, the third is 180 − 50 − 60 = 70°.
Work through this question

Triangle angles total 180°: 180 − 50 − 60 = 70°.

Now close the method and try the question again. Reading the method does not mark it complete.

INDEPENDENT · Q06

A cube has side length 3 cm. Volume?

Need a clue? Show me a step

Volume of a cube is side × side × side.

Show the method to use
  1. Area is inside a shape: for a rectangle use length × width.
  2. Perimeter is around a shape: add every side. An 8 m by 5 m rectangle has perimeter 8 + 5 + 8 + 5 = 26 m.
  3. Angles in a triangle total 180°. If two angles are 50° and 60°, the third is 180 − 50 − 60 = 70°.
Work through this question

Volume = 3 × 3 × 3 = 27 cm³.

Now close the method and try the question again. Reading the method does not mark it complete.

OPTIONAL CHALLENGE · OPEN RESPONSE

Design a rectangle with area 36 m². Find its perimeter, then find a different rectangle with the same area.

0 words · optional
0 / 6 completeComplete every problem to finish the data lab.

KEEP YOUR SKILLS SHARP

YOUR WEEKLY TRAINING

Four short sessions to spread across your week. Each has six problems and a reasoning mission. Allow about 10–15 minutes per session, and take longer when you need it.

Use paper for working. Enter numbers only; units are shown beside each answer. These are fictional practice scenarios.

0 / 24 correct
SESSION 1 · NUMBER CHECK0 / 6

LEARN THE METHOD

Work out brackets first, then powers (for example, 8² means 8 × 8). Next divide or multiply from left to right. Last, add or subtract from left to right. For fractions, make the bottom numbers match: 1/2 + 1/4 = 2/4 + 1/4 = 3/4.

WORKED EXAMPLE

18 + 4 × 3 = 18 + 12 = 30. But (18 + 4) × 3 = 66.

  1. Use a hint

    Multiply first: 8 × 3 = 24; add 97 to get 121.

  2. Use a hint

    Brackets first: 105 × 3 = 315.

  3. Check the method after trying

    8² means 8 × 8 = 64; subtract 3.

  4. Check the method after trying

    One quarter is 94; multiply by 3.

  5. Check the method after trying

    1/2 = 2/4, so 2/4 + 1/4 = 3/4 = 0.75.

  6. Check the method after trying

    (779 − 3) ÷ 8 = 97.

Compare your reasoning after trying

Multiplication is done before addition unless brackets change the order. For example, 2 + 3 × 4 = 14, but (2 + 3) × 4 = 20.

Your example may differ. Check your calculations and whether you explained why.

SESSION 2 · SIGNED NUMBER LAB0 / 6

LEARN THE METHOD

Negative numbers are below zero. A rise is positive; a fall is negative. Calculate change as final minus starting temperature.

WORKED EXAMPLE

From −6°C to 9°C: 6 degrees to zero and 9 more = a rise of 15°C. From 9°C to −6°C, the signed change is −15°C.

  1. °C

    Use a hint

    −3 + 98 = 95.

  2. °C

    Use a hint

    3 to zero, then 98 more: 101.

  3. °C

    Check the method after trying

    Final − start = −3 − 98 = -101.

  4. °C

    Check the method after trying

    The total is zero; zero divided by 3 is zero.

  5. °C

    Check the method after trying

    −98 + 3 − 4 = -99.

  6. °C

    Check the method after trying

    Add the readings and divide by 2: (98 − 3) ÷ 2.

Compare your reasoning after trying

No. −5°C + 8°C = 3°C, while 10°C + 8°C = 18°C. Equal changes do not imply equal starting or final values.

Your example may differ. Check your calculations and whether you explained why.

SESSION 3 · DATA INVESTIGATOR0 / 6

LEARN THE METHOD

Mean = total ÷ count. Median is the middle ordered value (average the middle pair if needed). Mode is most frequent. Range = maximum − minimum.

WORKED EXAMPLE

For 2, 4, 4, 6, 9: mean = 25 ÷ 5 = 5; median = 4; mode = 4; range = 9 − 2 = 7.

  1. Use a hint

    Total 408 ÷ 4 = 102.

  2. Use a hint

    Ordered: 99, 101, 102, 103, 108; take the middle.

  3. Check the method after trying

    107 − 97 = 10.

  4. Check the method after trying

    100 occurs three times.

  5. Check the method after trying

    Average the middle two: (101 + 105) ÷ 2 = 103.

  6. Check the method after trying

    Old total = 396; new total = 515; divide by 5.

Compare your reasoning after trying

A large outlier raises the total and mean. A larger sample can still be biased if it only includes one kind of respondent; selection matters as well as size.

Your example may differ. Check your calculations and whether you explained why.

SESSION 4 · BUILD + MEASURE0 / 6

LEARN THE METHOD

Rectangle area = length × width; perimeter = 2 × (length + width). Triangle area = base × perpendicular height ÷ 2. Cuboid volume = length × width × height.

WORKED EXAMPLE

For an 8 m × 3 m rectangle: area = 24 m² and perimeter = 22 m. A 6 m × 4 m rectangle has the same area but perimeter 20 m.

  1. m²

    Use a hint

    Length × width = 100 × 5.

  2. m

    Use a hint

    2 × (100 + 5) = 210.

  3. cm²

    Check the method after trying

    Base × height ÷ 2 = 200 × 5 ÷ 2.

  4. cm³

    Check the method after trying

    Multiply the three dimensions.

  5. °

    Check the method after trying

    180 − 45 − 62 = 73.

  6. m²

    Check the method after trying

    Whole area 500 minus uncovered area 4.

Compare your reasoning after trying

For example 12 × 2 and 6 × 4 both have area 24 square units. Their perimeters are 28 and 20 units. Area and perimeter measure different things.

Your example may differ. Check your calculations and whether you explained why.

Answers and reasoning save on this device when browser storage is available.

PROJECT HQ · PROJECT FILE 05

TEST — run first proper test.

Start something real. Build an idea, test it, improve it, and share it. Make your move.

TEST your Resilient Systems Challenge. Choose one variable or design feature, define what you will measure, compare it against a baseline and record what the result suggests you should change next.

MAP SYSTEM→FIND WEAK POINT→DISRUPT→DESIGN→TEST→REVISE→PRESENT

WEEK 5 · FIRST PROPER TEST · Run one fair test of your proposed system or improvement. Keep the comparison clear and record what actually happened.

Complete all five fields. Your Week 5 test log is saved on this device.

Project sharing will be optional. A future upload system must keep private submission separate from public-showcase/marketing permission.

CHECK-IN

What changed in your thinking?

YOUR WEEKLY GAME · TERM 3 / WEEK 5

Keep Your Cool

Compare insulation, draw a cooling-water network and protect an emergency tank during a heatwave.

PLAY KEEP YOUR COOL
Three missions · Touch and keyboard · Free field guide · Experiment and replay

YEAR 7 · SENIOR HOMEWORK CLUB

Your journey

0 of 36 weeks complete.
CONTINUE →
